KWS 8710..
Angled end support, series WS
- series WS: angular support with socket for invisible tube ends
- angled 45 degrees
- for visible fixing
- mounting material available separately
Material
stainless steel
clamping element:
aluminium
Dimensions (in mm)
| Art. no. | D | B | S | H |
| KWS 8710.. | tube, Ø 30 x 1,5 | 93 | 32 | 81 |
| KWS 8017.. | tube, Ø 33,7 x 2 (1 Inch) | 96 | 32 | 84 |
| KWS 8307.. | tube, Ø 35 x 1,5 | 96 | 32 | 84 |
| KWS 8H07.. | timber, Ø 35 | 96 | 32 | 84 |
