KWS 8121..
Straight mid support, series WS2 / WS4
- series WS2 / WS4: angular support with socket for visible tube ends
- for visible fixing
- mounting material available separately
Material
stainless steel, V2A (series WS2) or V4A (series WS4)
clamping elements:
aluminium
Dimensions (in mm)
| Art. no. | D | S | H |
| KWS 8121.. | tube, Ø 30 x 1,5 | 31 | 83 |
| KWS 8265.. | tube, Ø 33,7 x 2 (1 Inch) | 36 | 85,5 |
| KWS 8375.. | Tube, Ø 35 x 1,5 | 36 | 85,5 |
| KWS 8465.. | Tube, Ø 40 x 2 | 41 | 90,5 |
| KWS 8565.. | tube, Ø 42,4 x 2 (1,25 Inch) | 43 | 91,5 |
| KWS 8H75.. | timber, Ø 35 | 36 | 85,5 |
| KWS 8H15.. | timber, Ø 40 | 41 | 90,5 |
